- Two-Stage Air End
The most efficient Sullair Two-Stage Air End EVER- Innovative over/under design with integrated gearbox
- Patent-pending interstage cooling for increased efficiency and low pressure drop
- Lighter and more compact
- Optimized gearing for maximum efficiency
- Casting featuring internally ported lubricant passages
- Asymmetrical rotors designed, engineered and
manufactured in the USA - High-efficiency bearings in first and second stage
- Sullair OptimalAir® Air Filter
- High-efficiency/heavy-duty inlet filter holds up to five times more contaminant than conventional cellulose filters
- Cleaner intake air keeps fluid clean and extends component life
- 99.9% efficiency per ISO 5011
- Sullair Air-Fluid Separator
- Designed for low pressure drop, reducing energy requirements
- High-efficiency media maximizes oil removal from compressed air
- Low carryover (<2ppm) means fewer lubricant top-offs needed
- ASME and CRN approved
- Cooling System
- Heavy-duty, oversized cooling system designed for 46°C (115°F) applications
- Dual TEFC fan motors with VSD to help maintain stable discharge temperature—increasing efficiency
- Easy-clean access panels designed in the package
- Separate oil cooler and aftercooler reduces imbalanced temperature loads
- Motor
- Super Premium Efficiency (IE4) TEFC motors
Standard on Fixed Speed and Electronic Spiral Valve models - Premium Efficiency (IE3) TEFC motors
Standard on VSD models - Heavy-duty, slow running 1800 rpm design
- Extended life when compared to higher RPM motors
- 104°F (40°C) ambient motor temperature rating
- Class F insulation, Class B rise for higher temperature operation
- Genuine Sullube® Factory Fill
- Non-varnishing fluid protects and cleans your compressor
- Polyglycol base provides optimal viscosity and helps optimize operating temperatures
- Enhanced Sullair Touch Screen (STS) Controller
- 10˝ color screen for easy viewing and intuitive operation
- Menu-driven screens offer easy access to compressor controls
- Integrated graphing and trending to analyze compressor performance
- Sequencing up to 16 compressors
- AirLinx® Remote Monitoring
- Connect anywhere to keep an eye on compressor operation, and reduce the risk of unplanned downtime
- Monitor pressure, temperature, running hours and service hours
- Alerts for service and warnings
- Data stored at 15-minute intervals
- Customizable reporting, from Basic to Advanced
- Real-time information through cellular connection
- Wye-Delta starter
- Zero loss drain
- Phase monitor
- Enclosure with hinged panels
- Easily removable for service
- Standard full base frame
- Helps keep dust and debris out of the unit
- 10-Year Diamond Warranty*
*Maintaining the Sullair 10-Year Diamond Warranty requires using Genuine Sullair parts, Sullube®, and participation in the oil sampling program. Restrictions apply.
